Bourns 3006P 200k ohm Potentiometer(Pair of 5)

Product Title: Bourns 3006P 200K Ohm Potentiometer

Product URL: https://www.electratraders.com/products/bourns-3006p-200k-ohm-potentiometer

Description: This high-end Bourns preset is a must-have for any electronics enthusiast. Known as potentiometers, trimpots, and other names, it is a variable resistor that can be mounted on a PCB or breadboard. What sets it apart is its precision - it must be cranked ten times to change the resistance from 0 to full range, providing unparalleled accuracy in obtaining the desired resistance. With three leads, the outer two always have a resistance of 200K ohm, while the resistance between the outer pins and the center pin varies as the potentiometer is rotated.

Not only can this potentiometer be used as a variable resistor, but it can also generate a variable voltage. Simply connect the outer two pins to VCC and GND to use it as a variable resistor, and the middle pin will output a voltage between 0 (GND) and VCC as it is rotated. Made by Bourns, a trusted brand in the industry, this multiturn potentiometer has a maximum resistance of 200K ohm with a tolerance of 10%. It can withstand temperatures ranging from -55°C to 125°C and has a compact size of 20.8x5x6.6mm. Made in China, this potentiometer is a reliable and versatile addition to any electronic project.
